Description

Retekess TD156 Keypad Transmitter for Long Range & Waterproof Paging System

Waterproof and easy to clean

The keyboard is made of ABS material, waterproof and easy to clean, which is convenient for restaurants to remove dirt。

Touch buttons

Touch button design, more sensitive。

Long transmission distance

With antenna, the keypad of TD156 can reach up to 800 meters.

Compact design does not take up space

The size of keypad is suitable for saving space.

Application:

Spec

Keypad Transmitter
Dimensions 6.38 × 3.86 × 1.57 in
Housing Material ABS
Transmit Power 400 mW
Maximum Power 1 W
Transmit Frequency 424.8–469.025 MHz
Operating Voltage 12V / 1A
Key Type Touch-sensitive
Modulation FM
Keypad Transmitter
Dimensions 6.38 × 3.86 × 1.57 in
Housing Material ABS
Transmit Power 400 mW
Maximum Power 1 W
Transmit Frequency 424.8–469.025 MHz
Operating Voltage 12V / 1A
Key Type Touch-sensitive
Modulation FM

FAQ

Q: How does the TD156 restaurant pager system work?

A: After a customer places an order, staff gives the customer a pager and records its ID. When the order is ready, staff enters the corresponding ID on the transmitter keypad to send a page. The customer can then return to the pickup counter to collect the order and return the pager.

Q: What is the range of the TD156 pager system?

A: The TD156 pager system offers a range of up to 800 m (2,624 ft) in open areas. The actual range may vary depending on the surrounding environment.

Q: Are TD156 guest pagers waterproof?

A: Yes. TD156 pagers feature an IP67 protection rating, making them suitable for environments where water exposure is a concern.

Q: What alert options does the TD156 pager system offer?

A: TD156 pagers support vibration, audible alerts, and LED flashing. The vibration, sound, and LED flashing settings can be adjusted to fast, medium, or slow modes.

Q: How long is the standby time of TD156 pagers?

A: TD156 pagers offer approximately 48 hours of standby time.

Q: What pager IDs can be set on the TD156 system?

A: The TD156 keypad supports pager ID settings from 1 to 9,998, allowing different IDs to be assigned to pagers within the system.

Q: Can I adjust the out-of-range alarm time on the TD156?

A: Yes. The TD156 supports out-of-range alarm time settings from 0 to 30 minutes.

Q: Can I adjust the service countdown and reminder duration?

A: Yes. The TD156 supports service countdown settings from 0 to 99 minutes and reminder duration settings from 5 to 99 seconds.

Q: Can I customize TD156 guest pagers with my company logo?

A: Yes. Logo customization is available. Please provide your logo in PSD format so our team can prepare the design and printing.

Q: How can I quickly turn off TD156 pagers?

A: Place the pagers on the charging base, enter 0 on the transmitter keypad, and press the Call button to turn them off.
